Wuhan Kenxin Automation Technology Co., Ltd. focuses on the design and production of powder conveying solutions for the baking industry. Founded in 2010, the company has accumulated more than 16 years of experience in bakery equipment manufacturing and holds over 20 technical patents. The pneumatic flour feeding system is engineered to address common challenges in food powder handling, including moisture absorption, cross-contamination, dust emission, and weighing inaccuracy.
This automatic system supports both dilute phase negative pressure and dilute phase positive pressure pneumatic conveying methods. It is suitable for the transportation and automatic batching of various food powders in bakery processing facilities. The system can be customized to match specific plant layouts and production capacities, making it adaptable for different scales of business operations. All components that come into contact with food materials are constructed from stainless steel, ensuring compliance with food safety standards.
The system adopts a fully enclosed pipeline design that prevents flour from absorbing moisture and coming into contact with external contaminants. This design also eliminates dust emission into the workshop environment, reducing the risk of dust explosions during production. The enclosed structure maintains the quality and consistency of flour throughout the conveying process.
The pneumatic conveying system enables multi-directional transportation, including horizontal, vertical, and curved paths. This flexibility allows the system to adapt to complex plant spaces and existing production lines. It supports multi-point feeding and discharging, which facilitates the integration of different production processes and improves overall workflow efficiency.
The system features a relatively simple structure, consisting mainly of an air source, pipelines, dust collector, and separation device. This design results in low maintenance workload and reduced downtime. The system can be integrated with automatic batching and weighing systems to create a complete powder handling solution for bakery production.
Parameter | Specification |
|---|---|
Type | Flour Feeding System |
Material Type | Powder |
Feed Cylinder Structure | Multi-Room Feeding |
Filling Principle | Pressure |
Structure | Rotary |
Material | Stainless Steel |
Automatic Grade | Automatic |
Filling Valve Head | Multi-Head |
Dosing Device | Capacity Cup |
Packaging Container Lifting Structure | Pneumatic Lifting |
Air Source | 0.5-0.7 MPa |
Overall Dimensions | Customized |
Specification | Customized |
Origin | Hubei, China |
Parameter | Specification |
|---|---|
Conveying Method | Positive pressure/negative pressure pneumatic conveying |
Conveying Capacity | 2000-5000 KG/hour |
Electrical Components | Schneider |
PLC and HMI | Siemens |
Motor | SEW |
Frequency Converter | Mitsubishi |
Production Capacity | 2-5 ton per system |
Kenxin provides comprehensive customization services to meet the specific requirements of industrial clients. The company offers OEM and ODM solutions, including custom system design, size adjustment, and logo integration. All systems are designed based on on-site evaluations of client facilities to ensure optimal performance and compatibility.
The company operates a 24/7 after-sales service system to support clients worldwide. The service team provides installation guidance, commissioning assistance, and technical support throughout the product lifecycle. Kenxin has implemented the ISO9001:2015 quality management system, which ensures consistent product quality and reliable performance. The company's equipment has been adopted by numerous well-known food enterprises, including COFCO Xiangxue, Mankattan, and Tous les Jours.
We are a manufacturing company, Wuhan Kenxin Automation Technology Co., Ltd., located in Wuhan City, Hubei Province, China. We specialize in the research, development, production, and after-sales service of bakery food machinery.
Our flour feeding systems are constructed from food-grade materials, including stainless steel, food-grade aluminum, and aluminum steel. All materials comply with international food safety standards.
Yes, we offer full customization services. Please provide us with your detailed size requirements and plant layout information, and we will design a system that meets your specifications.
We support on-demand customization, including logo customization, color customization, and appearance size customization. Our design team will work with you to integrate your branding elements into the system.
To receive an accurate quote, please send us your specific production requirements, including conveying capacity, plant layout, and any special functional needs. We will develop a customized solution and provide you with a detailed price quotation based on your requirements.
