Kenxin Company is the first professional manufacturer and promoter of the full automated tunnel proofing system for racks. This automatic round trolley proofer system is designed for commercial bakery operations, suitable for various production lines including toast, hamburger, Chinese steamed bread, croissant, pizza, biscuit and cake. The system supports fully automatic continuous production, which helps streamline dough proofing processes in industrial food manufacturing facilities.
Parameter | Details |
|---|---|
Usage | Biscuit, Cake, Pizza, Bread |
Timing Device | With Timing Device |
Voltage | 380V |
Insulation Panel | 100mm Thick Polyurethane Foam |
Temperature Accuracy | ±1℃ |
Humidity Accuracy | +2% |
Humidification System | Dry Steam Humidifier (External Steam Source) |
Drive Motor | SEW Gear Reduction Motor |
Power Source | Electric |
Material | Stainless Steel |
Temperature Range | 35-40℃ |
Heating System | External Steam Source + Heat Exchanger |
Waterproofing | Arc-Designed Seams with Waterproof Treatment |
Total Power | 2kw |
Steam Consumption | 100kg/h |
Pressed Air | 0.5-0.7MPa |
Production Capacity | Customized according to requirements |
Overall Dimensions | Customized according to production capacity |
Annual Production Capacity | 1000 pieces |
Origin | Hubei, China |
Package Size | 1219.00cm × 243.00cm × 289.00cm |
|---|---|
Package Gross Weight | 3999.000kg |
Transport Package | Wooden |
Trademark | KENXIN |
The system features an innovative side slot-type propulsion mode, which enables automatic movement of charging skips according to preset proofing time. This design reduces manual labor intensity significantly. The standardized production process and menu-type control interface allow one-button switching between different product proofing processes. The equipment operates automatically without requiring constant operator presence.
Integrated with Kenxin temperature and humidity control technology, the system maintains overall temperature control within ±1℃ and humidity control within +2%. This precise control effectively solves the water accumulation problem inside the chamber. The reasonable spatial distribution of hanging baskets ensures uniform temperature and humidity throughout the proofing area, resulting in consistent product quality.
The system has a simple equipment structure with multiple safety protection mechanisms. It features automatic emergency shutdown and alarm functions in case of sensor or equipment failure. The arc-designed seams with waterproof treatment enhance durability. The compact structure occupies minimal floor space while enabling efficient continuous feeding and discharging.
This trolley proofer system supports on-line proofing with unattended operation throughout the production line, enabling fully automatic continuous production. The stable equipment movement prevents vibration of material trays, eliminating uneven proofing and air leakage issues. The system has a low energy consumption ratio, and the interior of the chamber remains dry without water accumulation. The whole machine is not restricted by plant floor conditions and can be customized based on production capacity, plant height and layout.
Kenxin provides comprehensive customization services for industrial clients. The system specifications, including production capacity and overall dimensions, can be tailored to meet specific operational requirements. Additional customization options include logo printing, color selection and appearance size adjustments to align with existing production line configurations.
Founded in 2010, Wuhan Kenxin Automation Technology Co., Ltd. specializes in program planning, equipment research and development, manufacturing, installation and commissioning, and after-sales service for bakery food machinery. The company holds more than 20 technical patents and has obtained ISO9001:2015 quality management system certification. With 16+ years of industry experience, Kenxin provides 24/7 after-sales service and supports OEM/ODM cooperation. Its equipment has been adopted by numerous well-known food enterprises.
We are a manufacturing company, Wuhan Kenxin Automation Technology Co., Ltd., located in Wuhan City, Hubei Province, China.
Our products are made of food-grade aluminum, aluminum steel and stainless steel.
Yes, the system can be fully customized. Please provide detailed size and production capacity requirements, and we will design a solution according to your specifications.
You can send us your specific requirements and production line details. We will customize a solution for you based on your needs and provide the exact price accordingly.
